Disassembly Instructions
|
29
6.0 Disassembly Instructions
Before disconnecting any components, follow the safety
information in the ETS-Lindgren Product Information Bulletin
included with your shipment.
Place the Model 3150B on a stable surface before disassembling.
As you remove parts, place them in a safe location. Store
disassembled components in secure, protective location. Retain
all fasteners.
See the corresponding step in Assembly Instructions on page 15 for detailed
information about how each component is attached.
