background image

Specifications

|

13

3.0 Specifications

Electrical Specifications

Frequency Range:

80 MHz to 1 GHz

VSWR (Average):

2:1

Maximum Continuous Power:

5 kW at 80 MHz, 2.5 kW at 1 GHz

Peak Power:

7 kW at 80 MHz, 4 kW at 1 GHz

Impedance (Nominal):

50

Ω

Connector:

7/16 female

Physical Specifications

Height:

203.07 cm (79.95 in)

Width:

209.07 cm (82.31 in)

Depth:

150.44 cm (59.23 in)

Weight:

10.56 kg (23.28 lb)
