The unique feature of the Model 3140B is the T bow tie elements. A T bow tie

increases the equivalent dipole electrical length, thereby decreasing resonant

frequency and increasing efficiency in the 20 MHz to 60 MHz range. Similarly, a

regular bow tie has a lower resonant frequency than an equal length single-wire

dipole. The T bow tie has the first resonance at a frequency where the length is

about 0.22

, a regular bow tie at a length of 0.3

, and a tuned dipole at about

0.48

. Thus at 50 MHz the 1.4 meter long T bow tie of the Model 3140B behaves

like a 2.8 meter tuned dipole. Cross-polar radiation is minimized because current

flow on one of the T end frames is almost exactly cancelled by the

oppositely-phased current on the other T end.

The standard self-balun feed of the log periodic also provides a matched

balanced feed to the bow tie elements. To prevent cable pickup below 100 MHz

and to improve matching to the bow tie elements, the Model 3140B contains a

balun transformer which acts as a common-mode choke to keep unbalanced

current off the coaxial feed cable outer shield, as well as adding some additional

inductance to improve impedance matching to the bow ties. Even though the

Model 3140B is highly balanced (symmetry +/- 0.5 dB), in vertically polarized

measurements cable position can effect results, so it is recommended that the

cable be suspended horizontally back from the antenna at least one meter before

any vertical drop. Below 150 MHz bow tie radiation dominates with a dipole-like

pattern, while above 150 MHz the radiation in the plane of the elements is

directional.

The Model 3140B is designed only for immunity testing. The large size

of the antenna makes it impractical for emissions testing where height

scanning is required, and the bow tie end plates increase the

measurement uncertainty when the antenna is polarized vertically. For

that reason, individual calibrations are not provided for the

Model 3140B.
