A

TTACH

M

ODEL

3140B

TO AN

ETS-L

INDGREN

O

FFSET

B

OOM

1.

Place the Model 3140B onto the offset boom with the attached

polarizing adapters flat against the top surface of the boom.

2.

Holding the Model 3140B securely, insert one 105861B 1/4–20 thread

insert into the underside of the offset boom.

3.

Attach the two mount knobs and tighten to secure the Model 3140B to

the offset boom.

Mounting Instructions

| 25
