4.0 Assembly Instructions

Before connecting any components, follow the

safety information in the ETS-Lindgren

Product Information Bulletin included with your

shipment.

Model 3140B Components

The Model 3140B BiConiLog™ Antenna consists of the following:

• Antenna

Bow tie elements (2)

Long T leg elements (2)

Diagonal struts (4)

V elements (2)

• Boom

assembly

Mount knobs (2): one 7/8-in (104169) and one 1/4-in (104136)

Polarizing adapters (100989) for booms with 7/8-in mount holes (2)

Thread inserts (105861B) 7/8 in-to-1/4 in (2)

Assembly Instructions
