You may wish to contact the retailer or the manufacturer if you are unable to find convenient local recycling
facilities as they have some legal responsibilities for recycling electrical products.
Please keep this instruction manual. If you give the appliance to anyone else, you must give them this
instruction manual, too!
MaIN coMpoNeNtS
1. Power switch
2. Power light
3. Grill tub
4. Grill grid
5. Cover to hold grill grid, heating element and grill tub
6. Stand legs
7. Stand shelf
8. Wing nuts, screws and washers to fix support legs and stand shelf
9. Stiffener rod to fix support legs
10. Heating unit
11. Power cable with plug (not represented on the figure)
poWer SUpply
the appliance should only be connected to 230V~ 50Hz electrical mains with a protective
earth connection. always verify that the mains voltage at the place of use is the same as
the voltage indicated in the rating label on the appliance.
USINg of applIaNce
Using the appliance
Warning!
The barbecue grill is a thermo-electric device which develops high temperatures during operation.
These may ignite flammable materials near to it, or can cause burn injuries when touched during
operation. To prevent fire and serious accidents, remove all flammable materials from the vicinity of
the appliance before starting to use it. Also wear heat insulating protective gloves during the use of
the barbecue grill. Before starting to operate the grill, warn users of other nearby appliances of the
potential hazards.
• Unpack the appliance and remove all the packing materials.
• Inspect the appliance and the accessories carefully to verify their soundness and undamaged condition. Only
perfectly sound and damage-free appliances may be connected to the electrical mains.
• After checking the appliance and accessories, clean the barbecue grill components with a slightly damp cloth.
After cleaning, let the device completely dry out.
Before use
1. You can use the appliance, without its support legs, on a table. In this case put a heat-resistant plate under the
appliance and continue assembling.
2. After cleaning, assemble the support legs first, then mount the stand shelf by using the screws, washers and
wing nuts. Ensure that the wing nuts are tight and stabilise the stand parts.
3. After positioning the stand correctly, slip it onto the seats formed on the bottom of the covering elements.
Ensure a safe, wiggle-free connection of the stand and barbecue grill.
4. Insert the grill tub and heating unit into the seat prepared into the upper part of covering element. Then
mount the grill grid into the grooves at the longitudinal sides of the cover. (Two kinds of heights can be set,
depending on where the grooves are into which the grid is being inserted.)
5. To operate the barbecue grill, select a location where the floor (or ground) provides a horizontal, wiggle-free
position. Keep away any flammable material from the vicinity of the device and keep a distance of at least 15
cm between any of the sides of the grill and the walls! When installing the device, comply in all cases with the
contents of the section „Important Safety Instructions” to prevent fire and hazardous situations.
Using of appliance
1. Fill the grill tank with cold tap water up to the maximum mark on its internal wall. When filling up with
water, take particular care not to allow water droplets to get onto the heating element. During operation,
pay attention to the water level and don’t allow it to lower significantly. If the grill operates with a very low
level of water, your device can be damaged or overheat. If you refill the grill tank during use, you must always
unplug the power supply cable from the wall socket or extension. During refilling, you must always prevent
water from getting onto the hot heating element.
2. When refilling is complete, plug the device into the power supply then switch it on with the main switch.
Operating status is indicated by a red light.
3. When the device is first used, the new grill may emit a slight odour, which soon dissipates. After this, the
barbecue grill is ready to use. The heating element heats up to cooking temperature 6 to 8 minutes after
connection to the power supply.
4. Put the food to be grilled, directly onto the grill grid. Don’t put the food on plates, trays, alu-foils or other
objects.
