44

Global Parameters Data Dump

Status

Description

1111 0000

System Exclusive (SysEx)

0000 0001

DSI ID

0010 0101

Mopho ID

0000 1111

Main Parameter Data

0vvv vvvv

20 nibbles (LS then MS) for 10 Global parameters. Global Parameters
are listed starting on page 34.

1111 0111

End of Exclusive (EOX)

Note: The Global Parameters Data Dump is not recognized when received; it is
only transmitted when requested. NRPN messages are used to change Globals.

Packed Data Format

Data is packed in 8 byte “packets”, with the MS bit stripped from 7 parameter
bytes, and packed into an eighth byte, which is sent at the start of the 8 byte
packet.


Example:

Input Data

Packed MIDI data


1 A7 A6 A5 A4 A3 A2 A1 A0

1 00 G7 F7 E7 D7 C7 B7 A7

2 B7 B6 B5 B4 B3 B2 B1 B0

2 00 A6 A5 A4 A3 A2 A1 A0

3 C7 C6 C5 C4 C3 C2 C1 C0

3 00 B6 B5 B4 B3 B2 B1 B0

4 D7 D6 D5 D4 D3 D2 D1 D0

4 00 C6 C5 C4 C3 C2 C1 C0

5 E7 E6 E5 E4 E3 E2 E1 E0

5 00 D6 D5 D4 D3 D2 D1 D0

6 F7 F6 F5 F4 F3 F2 F1 F0

6 00 E6 E5 E4 E3 E2 E1 E0

7 G7 G6 G5 G4 G3 G2 G1 G0

7 00 F6 F5 F4 F3 F2 F1 F0

8 00 G6 G5 G4 G3 G2 G1 G0

This explains why it takes 293 MIDI bytes to transmit 256 Program data bytes.

Hidden Functions

Hold the A

SSIGN

P

ARAMETER

switch and hit the +/increment switch to calibrate

the low-pass filter and analog oscillator waveshapes. This should not be
necessary for normal operation.

Another (literally) hidden function: Carefully insert a small, standard
screwdriver into the hole in the bottom panel to adjust the LCD contrast.
