Page 4
SWT - Version A - Released 12 March 2013 - Copernicus Educational Products Inc.
1
Attach Stretchers to Long End Frames
You will need:
(Not to Scale)
Actual Size:
Long End Frame
x 2
M6x35mm Bolt
x 6
Side Stretcher
x 2
M6 Lock Washer
x 6
A
C
Middle Stretcher
x 1
Note orientation,
wire tub stops face outwards
Leave hardware loose for next step
A
C
This
side up
Note orientation of middle stretcher
Bend faces upwards, see label
