Step 1,2 – Copernicus RC105-ECO1 User Manual
Page 4

RC105 - Version B - 25 August 2014 - Copernicus Educational Products Inc.
1
Install Casters
Base x 2
Caster x 4
You will need:
(Not to Scale)
Actual Size:
Front
2
Center Frame x 1
Lower Frame
1 Left, 1 Right
x 2
You will need:
(Not to Scale)
x 4
x 4
Actual Size:
A
D
!
!
Note - Front of
base is the end
with the brake
Install Center Frame &
Rear Frame Lower
Note - L & R stickers
on the frames
!
Press Casters firmly into the Base:
?
Casters will click into place
?
If necessary, tap the caster in
using a rubber mallet.
R
L
A
D
A
D
A
D
A
D
!
