IMPORTANT: Please be sure to check that the product is properly fused. Installing the XT3xx LED
light without the appropriate fuse will void the warranty.
Specifications
XT302 XT304 XT308
Input Voltage 11-30 VDC 11-30 VDC 11-30VDC
Peak Input Current 1 Amp 2 Amp 4 Amp
Output Power 6 W 12 W 24 W
Flash Patterns 22 31 31
Fuse
(customer supplied)
2A 3A 5A
Mounting
Mount the XT3xx LED light using the brackets supplied and user supplied mounting screws.
CAUTION: Be certain that you have selected a mounting location that does not obstruct the driver’s vision and
allows safe operation of the vehicle. Check the chosen mounting location to ensure that the vehicle’s structure
and material is adequate to support the weight of your light.
Operation
Install the Function Switch (User Supplied) to the Warning Light. The patterns are changed
with the BLUE wire. To advance to the next pattern, apply BLUE to the BLACK wire for less than
1 second. To cycle backwards to previous patterns, apply BLUE to the BLACK wire for 1-3 second.
To reset to the factory default pattern, apply BLUE to the BLACK wire for 3-5 second. To turn off
power, apply BLUE to the BLACK wire for more 5 second.
