LED module housings may become hot with extended use. Allow modules to cool complete-
ly before attempting to remove.
WARNING!
TROUBLESHOOTING
Problem Probable Cause Remedy
Lighthead does not activate a. No power to unit a. Check wire for loose connection
b. Power input wire reversed b. Reverse power wires
c. Damaged or shortaged cabling c. Check cables for damage
d. Defective lighthead d. Replace lighthead module
Lighthead is constantly ON a. Control wire permanently
grounded or shorted to GND
a. Avoid permanent grounding of
control wire
Setting the Flash Pattern:
Push and hold either of the white oblong buttons in the center of the Visor Light as follows
- Less than 1 second for the NEXT pattern
- 1 to 3 seconds for the PREVIOUS pattern
- 3 to 5 seconds for the P13 QUAD FLASH 75FPM PHASE 1 pattern
- Greater than 5 seconds to TURN OFF the LED Light Head
Synchronization:
The (2) Par 36 lightheads in the LED Visor Light are synchronized from the factory. To configure the two light-
heads to alternate their patterns, advance the pattern of either beacon to the Phase 2 mode of the current pat-
tern. Please note that some flash patterns do no synchronize well together due to the timing required between
flash sequences. The user should visually confirm that the selected flash patterns are providing the desired
result.
Maintenance:
The LED Visor Light with PAR36 Modules is designed to be maintenance free. Refer to the guide below for
help with troubleshooting. Should the unit be diagnosed as malfunctioning, remove unit and replace with a new
module.
