Troubleshooting
All SuperVisors® are thoroughly tested prior to shipment. However, should you encounter a problem during installation or during the
life of the product, follow the guide below for information on repair and troubleshooting. Additional information may be obtained from
the factory technical help line at 314-996-2800.
Follow the guide below for information on repair and troubleshooting.
TROUBLESHOOTING GUIDE
Note: TriCore
®
Modules must be replaced as a module. There are no user serviceable parts.
PROBLEM
TriCore Module not
operating when
powered.
QUESTIONS
POSSIBLE CAUSE
a. Bad power/ground
connection.
b. Defective module.
SOLUTION
a. Fix connection.
b. Replace module
N/A
Parts List
Reference Number
Part Description
Part Number
1 Outer Mtg. Brkt. Dodge Charger Pass Side
T15340
2
Cover
T15335 Dome Light Version = T15434
3 Inner Mtg. Brkt. Dodge Charger
T15341
4
Blank Brkt. Crown Vic
T15056
5 Outer Mtg. Brkt. Dodge Charger Drivr Side
T15336
6
Outer Panel
T15333 Dome Light Version = T15433
7
TriCore® Module
Contact Code 3, Inc for P/N
8 Circuit Board Assembly
T11568
9 Light Blocker Bracket Dome Light version -Not Shown T15439
Any disassembly of any of the TriCore light heads will result in loss of warranty coverage on the
equipment.
