CRATE CR-1
LIMITED EDITION GUITAR AMPLIFIER
Technical Specifications:
OUTPUT POWER RATING 5 W RMS @ 10%THD, 8 ohm load, 120 VAC
INPUT IMPEDANCE 1 M ohm
MAX. SIGNAL ACCEPTED 2v peak-to-peak
SIGNAL TO NOISE RATIO 70dB typ
GAIN 60dB w/ Gain switch off, 90dB w/Gain switch on
TONE CONTROL 33dB @ 10kHz
LINE OUT LEVEL 0.5V RMS
INTERNAL SPEAKER 10”, 8 ohm, 30 W
PREAMP TUBE (1) 12AX7A
POWER AMP TUBE (1) EL84
POWER REQUIREMENTS 120VAC, 60Hz, 60VA
100/115VAC, 50/60Hz, 60VA
230VAC, 50/60Hz, 60VA
SIZE AND WEIGHT 17-14” H x 15-1/4” W x 9”D; 21 lbs.
Crate continually develops new products, as well as improves existing ones. For this reason, the
specifications and information in this Crate manual are subject to change without notice.
P/N 47-879-01
071403
