Page 11
1
11
1
System Block Diagram:
CRATE CR-1
LIMITED EDITION GUITAR AMPLIFIER
INPUT
GAIN
ON/
OFF
VOLUME TONE
SPEAKER
LINE OUT
12AX7A
V1A
12AX7A
V1B
EL84
V2
Declaration Of Conformity
#35, Effective 01-01-2001
Manufacturer’s Name:
SLM Electronics
Production Facility:
11880 Borman Drive, St. Louis, MO 63146, USA
Production Facility:
700 Hwy 202 W, Yellville, AR 72687, USA
Shipping Facility:
1400 Ferguson Ave., St. Louis, MO 63133, USA
Office Facility:
1400 Ferguson Ave., St. Louis, MO 63133, USA
Product Type:
Audio Amplifier
Complies with the following Standards:
Safety:
EN60065, E60065, C22.2, UL6500 and/or UL813
EMC:
Directive 89/336/EEC, EN55103, EN55013, EN61000,
and/or FCC 47CFR 15B clA
Supplementary information provided by:
SLM Electronics - R & D Engineering
1901 Congressional Drive, St Louis, MO 63146, USA
Tel.: 314-569-0141, Fax: 314-569-0175
