14 V10.14
Power Supply Requirements
EVAPORATOR CONDENSING UNIT
SPLIT
SYSTEM
FAN AMPS @ 115V/60HZ POWER INPUT WATTS
UNIT AMPS @
115V/60HZ
POWER
INPUT
MODEL MCA HIGH MED LOW HIGH MED LOW MCA LRA WATTS
4000S/Sh 1.7 1.4 1.1 1.0 159 122 107 9.0 32.7 580
8000Swc 3.5 2.8 2.2 1.9 318 244 214 11.9 48.0 760
NOTES:
SPLIT
SYSTEM
SYSTEM AMPS POWER INPUT WATTS
MODEL MCA LRA HIGH MED LOW
4000Swc/
4000Shwc
10.4 32.7 739 702 687
8000Swc 14.7 48.0 1078 1004 974
NOTES:
Option A: Dual Power / Valve Control
Option B: Single Power / Electronic Control
1) A 15 amp dedicated circuit breaker (non GFI) is recommended for 4000Swc/4000Shwc systems.
2) A 20 amp dedicated circuit breaker (non GFI) is recommended for 8000Swc systems.
1) Separate 115V / 60HZ power supplies are required for the Evaporator and the Condensing Unit.
2) A 15 amp circuit breaker is recommended for all Evaporator models.
3) A 15 amp dedicated circuit breaker (non GFI) is recommended for 4000Swc/Shwc Con-
densing Units
4) A 20 amp dedicated circuit breaker (non GFI) is recommended for the 8000Swc Condensing Unit.
SINGLE 115V 60HZ POWER SUPPLY TO/FROM
EVAPORATOR
