Scale calibration
Calibration Configuration Settings –
The scale is configured from the factory to match the specified settings for each unit, as defined by the product
specifications and sales brochure. Modification of the setting can be accomplished by altering user configuration
settings P7-P10. Caution: Calibration and/or configuration of calibration settings of your scale should be
accomplished by a trained service technician using certified weights to ensure proper operation and accuracy.
Calibration is not covered under warranty.
Setup Controls
Config
Menu
Avail.
Settings
Default Definition Detailed Setting
P7 00-31 See table 2A Displayed Resolution (00) = 500 (08) = 2400 (15) = 7000
(01 )= 600 (09) = 2500 (16) = 7500
(02 )= 750 (10 )= 3000 (17) = 8000
(03 )= 800 (11) = 3500 (18) = 10,000
(04) =1000 (12 )= 4000 (19) = 12,000
(05 )=1200 (13) = 5000 (20) = 15,000
(06) =1500 (14) = 6000 (21-31) = N/A
(07) = 2000
P8 0,1,2 See table 2a Division Increment 0 = 1 ; 1 = 2 ; 2 = 5
P9 0-5 See table 2a Decimal Position 0 = 123456 ; 1 = 12345.6; 2 = 1234.56 ;
3 = 123.456 ; 4 = 12.3456 ; 5 = 1.23456
P10 0, 1 See table 2a Calibration weight 0 = KG ; 1 = LB
Table 2a
You may choose to configure your scale for a higher resolution. The factory does not recommend increasing the
resolution above 7,500 divisions for a stable weight reading. Certain environments may cause the scale to be
unstable at factory settings, reduce the # of division settings to increase your stability.
Calibration Menu
Calibration can be done with 25% to 100% of requested load and can be calibrated with 1 or 2 calibration points
Units
Change flashed digits
Tare
kg
Saves data and move down
to next Parameter setting
.
On/Off
Zero
Exits setup mode
Hold
Print
kg
Moves flashing digit
Hold
Print
kg
Moves flashing digit
Units
Change flashed digits
Tare
kg
Saves data and move down
to next Parameter setting
.
On/Off
Zero
Exits setup mode
