AVer SD1306 user manual - Manual (Page 7)

3
Network
Ethernet 10/100 Base-T
Network Protocol
IPv6, IPv4, HTTP, HTTPS, SNMP, QoS/DSCP, Access
list, RTSP, TCP/IP, UDP, SMTP, FTP, PPPoE, DHCP,
DDNS, NTP, UPnP, 3GPP (video only), SAMBA,
ONVIF
System
Video Resolution 1280x1024@30fps, 1280x960@30fps,
640x480@30fps, 320x240@30fps, 176x144@30fps
Video Adjust AES, Sense Up, Sharpness, D-WDR, Shutter Speed,
Sense-Up, AGC …etc.
Triple Streaming Yes
Image Snapshot Yes
Full Screen Monitoring Yes
Compression Format H.264/ JPEG/ MPEG-4
Video Bitrate Adjust CBR, VBR
Motion Detection Yes, 1 area (whole view)
Triggered Action Mail, FTP, Save to microSD/microSDHC card, Relay,
SAMBA
Pre/ Post Alarm Yes (Pre: 5 secs/Post: 5 secs)
Security Password protection, IP address filtering, HTTPS
encrypted data transmission, QoS/DSCP
Firmware Upgrade HTTP mode, can be upgraded remotely
Simultaneous Connection Up to 8
