Mounting the IP Camera
1. Use the supplied 2 sun shield bolts and
secure the sun shield on the IP camera.
2. Place the sticker on the wall surface. Then
spot the mark and drill the 4 holes
indicated on the sticker. It’s not necessary
to drill the biggest hole if you are going to
run the wire on the side.
3. Insert the 3 plastic anchors in the wall.
Place the washer on the 3 screws and
secure the mounting bracket on the wall.
4. Hook the IP Camera and use the hex
socket cap bolt to secure the IP camera on
the mount bracket.
