AVer Rugged Bullet Installation Guide - Manual (Page 14)

12
Technical Specifications

SF2121H-BHR-30 / SF2121H-BHR-50
Model SF2121H-BHR-30 SF2121H-BHR-50
Lens spec. CBC AG3Z0312LMRP-N
Lens type vari-focal Lens (Board mount, M19)
F/no F/1.2
Iris type DC Iris
Focal length f3~9mm
View Angle
H 121.2°(W)~38.1°(T)
V 62.1°(W)~21.3°(T)
Camera image
Min. illumination
0.2 Lux in day mode (IR off)
0.03 Lux in night mode (IR off)
0 Lux in night mode (IR on)
Built-in LED Yes
IR distance 30M/50M
Built-in mechanical ICR Yes
Auto IRIS Yes
Video
Compression H.264/MPEG-4/MJPEG
Max. resolution 1920 x 1080
Frame rate 1920 x 1080 @ 30fps
H.264/MPEG-4
bit rate mode
VBR, 5 levels
CBR, 64/128/512/768Kbps & 1/2/3/4/6/8/10/12Mbps
MJPEG quality 5 levels
Regional of Interest Yes
Smart Stream Yes, 5 windows
Image orientation mirror, flip
Motion Detection zones 3
Privacy mask areas 3
