Power over ethernet connection – AVer Rugged Bullet Installation Guide User Manual
Page 7
5
ENGLISH
Power over Ethernet Connection
Rugged bullet type camera is fully complies with PoE standard. It allows you to use PoE enabled
switch or PoE injector to transmit data and power thru single Ethernet cable.
PoE Enabled Switch Connection Diagram
PoE Switch
PoE Injector Connection Diagram
PoE Injector
Power cable
W
all outlet
Ethernet Switch
