DOOR ASSEMBLY
1
INSTALLATION MANUAL
INTERIOR
SHOWER SIDE
1a
1a.
1b.
6
Install the rollers on the door panel so that the rollers point towards the outside of the shower.
The vertical handle must always be on the opening side of the door towards the outside of the shower.
Install the bottom sliders on the door panel while placing the hooks towards the outside of the shower.
Place the bottom slider cap over the screw.
1b
INTERIOR
SHOWER SIDE
26
4
27
