6door panel assembly – Alumax K-NC91Z User Manual
Page 17
6
DOOR PANEL ASSEMBLY
6a
17
INSTALLATION MANUAL
Place the top rollers of the door panel on the top track and push on the bottom sliders to engage them into the bottom track.
Slightly unscrew the nut of the top rollers of the door panel this will allow you to adjust the door. Screw it back by ensuring
verticality with the level.
Place the expander caps on the expanders.
6a.
6b.
6c.
6b
6a
6c
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
INTERIOR
SHOWER SIDE
26 29 31
27
6b
