INSTALLATION MANUAL
Secure the panels with the screws 3/8” (x6)
ensuring that the magnetic gaskets
are still in contact .
Place the caps on the heads
of apparent screws.
Remove
the plier after
the pannels
are secured.
INSTALLATION DE LA BARRES DE SUPPORT /
SECURE THE EXPANDERS 7
7a.
16
18 17
FIX PANEL INSTALLATION (CONTINUED) 6
6i.
6j.
6k.
7a
REMOVE THE
PLIERS.
7b.
7b
Replace the doors on the base threshold.
Reinstall the back side of the hinges.
Remove the spacing blocks and make sure that magnetic gaskets are
still aligned and in contact.
6i 6j
6k
