12
INSTRUCTION MANUAL
2
3
10A
2
9B
3b
17
16a
16b
FASTEN THE “U” CHANNEL.
9
9B. Realign the aluminum “u” channel on the threshold and
drill a hole using a 1/8˝ drill bit at about 2˝ from the edge.
Put a drop of silicone in the hole and fasten the “u” chan-
nel with a 3/4˝ long screw (#19). Place the clear setting
block (#14) back over the screw.
OPTIONAL
RUN A BEAD OF SILICONE IN THE
ALUMINUM “U” CHANNEL.
9A. Mark the location of the aluminum “u” channel (#4) on
10B
10C
10A.
the aluminum “u” channel. Secure it with the locking
plier.
10B. Combine the 3 3/8˝ screws (#17) with the inner
10C. Snap the screw caps (#16a) on the screws.
INTERIOR
SHOWER SIDE
INSTALL THE FIXED PANEL.
10
19
14
19
9A
4
5
