INSTALLATION MANUAL
5
DOOR PANEL INSTALLATION (CONTINUED)
Adjust the wall jambs and the expanders so that
the doors are closing properly.
The magnetic gaskets must be
aligned and in contact.
Level and mark the positions of the
U channels on the base.
5e.
5g.
5f.
Remove the back side of the hinges, the door and panels .
Top
view
5e
5f
5g
