INSTALLATION MANUAL
DOOR PANEL ASSEMBLY
3
Use a mallet to install the magnetic gasket on the door panel.
3a
3b.
THE MAGNETIC GASKET IS
LONGER THAN THE DOOR
PANNEL AT THE BOTTOM.
Screw the handle on the door as illustrated.
3a.
3b
THE MAGNETIC GASKET
MUST BE IN LINE WITH THE
DOOR ON TOP.
11
Hinged
Fix Panel
Side
8
13
Magnetic
door gasket
side
