(2) on the walls on both sides of shower as well

as the placement of the bottom glass clips

(11) (13).

Remove the fixed panel assembly so as to allow

placement of the threshold (15) onto the base.

Ensure that a bead of silicone (S) is applied to

the underside of the threshold before installing.

Secure glass clips (11) (13) with self-drilling

screws (19).
