11
▃▆█
▃▆█
▃▆█
▃▆█ HDMI1 [CH10] WIDE Off 1280x1024
Press again to change Channel
Press the “Channel” button again within 5 seconds to switch Channel manually.
▃▆█
▃▆█
▃▆█
▃▆█ HDMI1 [CH 8] WIDE Off 1280x1024
Press again to change Channel
Press the WIDE button of RCU for longer distance transmission of audio/video contents.
(1) Press once for current WIDE mode status displayed on the OSD (Default is disable) :
▃▆█
▃▆█
▃▆█
▃▆█ HDMI1 CH10 [WIDE Off] 1280x1024
Press again to switch WIDE mode
(2) Press WIDE button again within 5seconds to switch WIDE mode status, OSD Displayed :
▃▆█
▃▆█
▃▆█
▃▆█ HDMI1 CH10 [WIDE On] 1280x1024
Press again to switch WIDE mode
NOTE :
Only the status of the RECEIVER connected to the HDTV can be displayed on the OSD. The
status of the TRANSMITTER HDMI out can not be displayed.
