Aero Twin ATRS-100 - Manual (Page 4)

Aero Twin, Inc. Remote Nose Gear Strut Servicing Port Installation and Maintenance Instructions
Kit No. ATRS-100 Document No. ATRS1-IM
Page 4 of 6
Revision: A, dated: 02/13/03
Read all instructions prior to beginning installation.
Introduction:
The Aero Twin Inc. Remote Nose Gear Strut Servicing Port is intended to provide easier access for
servicing the nose gear strut on Cessna 206 & 207 aircraft. The new port consists of an aluminum
block that is mounted to the right side of the nose gear tunnel, with a hose connecting this block to
the original port at the top of the nose gear strut.
Applicability:
The Remote Nose Gear Strut Servicing Port is applicable to all Cessna 206 & 207 series aircraft. The
206 series aircraft were produced with two sizes of valves in the top of the nose gear strut; Aero Twin
Inc.’s kit provides fittings for each. Suitability can be determined by aircraft serial number.
Kit Parts List:
Kit No. ATRS-100:
Figure 2 Item Number Part Number Description Qty
1 ATRS-101 Mounting Bracket 1
2 AN816-4D Nipple 2
3 S1827-1 Valve 1
4 MS20813-1 Valve Cap 1
5 AN3-7A Bolt 2
6 MS21044N3 Lock Nut 2
7 AN960-10 Washer 4
8 ATRS-102 Backing Plate 1
9 --- Gear Tunnel Skin ---
10 AE4036E0132-135 Hose Assembly 1
11 PA050354 Adapter 1
12 AN901-5A Aluminum Washer 1
Aircraft Serial Number Configuration
S/N 206-0001 thru 206-0275 A
S/N U206-0276 thru U206-1371 A
S/N P206-001 thru P206-0600 A
S/N U206-1372 and on B
S/N P206-0601 and on B
All Cessna 207 models B
Aircraft listed above with serial numbers falling in configuration A use item numbers 11 and 12 of
the Kit Parts List in the top of the nose gear strut, whereas aircraft in configuration B use item
number 2. See the Setup and Installation instructions below for more details.
