English
Owner
’s manual
8
TB741P/TB742P/TB743W
6. REMOTE CONTROL
Inserting the Battery
1. Turn the remote control unit over, then slide
the rear cover in the direction of the arrow.
2. Insert the AA (SUM-3/1.5V) batteries that
came with the remote control unit facing in
the directions shown in the figure, then close
the rear cover.
Notes:
Using batteries improperly can cause them to
explode. Take note of the following points:
• When replacing batteries, replace both batteries
with new ones.
• Do not short-circuit, disassemble or heat
batteries.
• Do not dispose of batteries into fire or water.
• Dispose of spent batteries properly.
Receiver for remote
control unit
Signal transmitter
Operating range: 30˚ in all directions
w
z
d a
[POWER]
[BAND/RTN/ADJ]
[DISP]
[PS/AS]
[1-6]
Rear side
AA (SUM-3/1.5V)
Batteries
Rear cover
Remote control unit
