TB741P/TB742P/TB743W
21
English
Installation and Wire
connection manual
1.
BEFORE STARTING
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “-”
terminal before starting. This is to prevent
short circuits during installation. (Figure 1)
2.
PACKAGE CONTENTS
1 Main unit
2 Manuals
Owner’s Manual & Installation Manual
3 Connection lead
4 Bag for accessories
Flat head screw (M5
✕ 8) .......................... 4
Sems hexagonal bolt (M5
✕ 8) .................. 5
Electro tap .................................................. 1
Hook plate .................................................. 2
Cable tie ..................................................... 1
Rubber cap ................................................ 1
Special screw ............................................. 1
5 Remote control unit
6 Battery (SUM3)
7 Outer Escutcheon
Figure 1
Car battery
TB741P
TB742P
TB743W
Installation and Wire connection manual
3.
GENERAL CAUTIONS
1. Do not open the case. There are no user
serviceable parts inside. If you drop anything
into the unit during installation, consult your
dealer or an authorized Clarion service
center.
2. Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner, benzine, or
alcohol, etc. For tough dirt, apply a little cold
or warm water to a soft cloth and wipe off
the dirt gently.
