1
3392505
FRAME - LARGE WHITE (LEXAN)
40
1480070
SHAFT - DRIVE
79
9430160
>WASHER - STAR 5/16"
2
4427005
NOSE DECAL MAGNUM
41
9250002
PIN - DRIVE SHAFT 3/16" ROLL SS
80
2200109
>OFFSHORE SALTWATER RELEASE
3
9040040
HOOK - 1/4" - 20 ROLLED
42
0467695
BRAKE PLATE - REEL
81
3992300
SWIVEL HEAD ASSEMBLY
4
2263102
NUT - HEX 1/4"-20
43
1264670
CLUTCH PAD
82
0267001
►
SIDE PLATE (RH)
5
9280750
SCREW - 1/4" - 20 (RH) x 3/4" PPH
44
1433074
GEAR - DRIVER WORM
83
0267002
►
SIDE PLATE (LH)
6
0849615
BASE LOCK KNOB
45
9010003
BEARING - DRIVE SHAFT NYLINER
84
0269726
►
PULLY - SWIVEL HEAD
7
9040340
BOLT - 3/8"-16 X 1-1/2" HEX
46
9400005
SPRING - SHAFT CONTACT
85
3397300
►
WASHER - .735 OD X .36 ID
8
9010001
BEARING - REEL SHAFT NYLINER [2.EA]
47
4421002
COVER - GEAR CASE
86
9010070
►
HDW BEARING BRASS[2.EA]
9
9430210
WASHER - 1-1/16" OD X 7/8" ID (NYLON)
48
2372100
SCREW - #8 x 5/8" PPHMS [5.EA]
87
2227820
BOOM END - TELESCOPIC (LEXAN)
10
0220477
DEPTH COUNTER - 3 DIGIT
49
9010310
WASHER - THRUST [2.EA]
88
2200148
SNAP & INSULATOR [2.EA]
11
0833561
GEAR - COUNTER
50
9010280
BEARING - THRUST
89
1007334
MOUNTING BASE (LEXAN)
12
3397912
REEL ASSEMBLY - TS ELECTRIC
51
2998906
KNOB BRAKE
90
2994893
*BAG ASSEMBLY, MOUNTING (KIT #3)
13
0233560
>GEAR REEL
52
0649001
►
KNOB - HAND ADJUST
91
2263102
NUT - HEX 1/4"-20 [4.EA]
14
3397902
►
REEL - 3.75" SS
53
9130390
►
NUT - KNURLED INSERT 3/8"-24
92
2371712
WASHER - 9/32" FLAT [4.EA]
15
1459666
REEL MAGNET [2.EA]
54
1479070
O-RING - REEL SHAFT
93
9100100
TERMINATOR
16
1480071
SHAFT - REEL
55
9370205
SCREW - 1/4" x 3/4" HEX WASH HD [3.EA]
94
9100101
TERMINATOR CUSHION
17
9340131
SCREW - SET 5/16"-18 x 1-3/4" (REEL)
56
3993200
POWER CABLE ASSEMBLY
95
9100620
TERMINATOR SNAP & SWIVEL
18
3775397
SPOOL CABLE SS [400.FT]
57
3393200
>POWER CABLE - BATTERY
96
9280725
BOLT - TRUSS 1/4" - 20 x 2-1/2" [8.EA]
19
9100070
CABLE LEADER SLEEVE [2.EA]
58
3393201
>CAP - POWER CABLE - BATTERY
97
9370010
SCREW - #4 x 1/2" PPH [3.EA]
20
3396534
MOTOR HOUSING - MAG 20 TS (LEXAN)
59
3393202
>POWER CABLE - MOTOR
98
9950357
WASHER - LOCK 1/4" SPLIT [4.EA]
21
1497071
LENSE - WINDOW DISPLAY
60
3393210
>CAP - POWER CABLE -MOTOR
99
3392010
TELESCOPIC BOOM SS
22
3395601
DECAL - LARGE, MAG 20 DT/TS
61
1458001
MOTOR 12V DC
100
2219822
>BASE TUBE CLAMP
23
3395700
DECAL - POSITIVE ION CONTROL TS
62
1497070
GEAR - WORM MOTOR
101
2219823
>MID TUBE CLAMP
24
2286792
SWITCH - UP/DN CONTROL
63
9250001
PIN - MOTOR, 3/32" X 3/4" ROLL SS
102
2222825
>MID TUBE COLLET
25
2286793
WASHER - SHIM .750 x .1 UP/DN SWITCH
64
700032
TERMINAL - MOTOR, FEM 12-10 [2.EA]
103
2222826
>BASE TUBE COLLET
26
3395701
DECAL - PIC KNOB DIAL TS
65
9010002
BEARING - MOTOR SHAFT
104
3392001
►
BOOM BASE TUBE (SS)
27
050268
CABLE ASSY - MAG20DT (DATA IN/OUT)
66
2263112
NUT - HEX #10-32 BZ
105
3392002
►
BOOM MID TUBE (SS)
28
050215
POSITIVE ION CONTROL POT
67
3390201
COVER - MOTOR HOUSING TS (LEXAN)
106
3392003
►
BOOM END TUBE (SS)
29
611005
KNOB - POSITIVE ION CONTROL
68
3393400
SCREW - #8-18 x 1-1/4" PPHSMS SS [6.EA]
107
2998905
SWIVEL BASE
30
700176
CAP - CONNECTION PORT [2.EA]
69
701007
O-RING - SMALL
108
2249001
>KNOB - RELEASE PIN (LEXAN)
31
609209
CABLE ASSY - MAG20DT UP/DN SWITCH
70
2332103
SCREW-#6-20 X 3/8"
109
2267001
>BASE PLATE (LEXAN)
32
609253
CABLE ASSY - ANTENNA IN (SENSOR)
71
3395632
DECAL - CANNON LARGE TS [2.EA]
110
2267002
>SWIVEL PLATE (LEXAN)
33
1234002
INSERT - 1/4" PRESS THD #6-32
72
3991903
BAG ASSY - REAR ROD HOLDER TS
111
2267006
>INDEXING PLATE (TAPPED)
34
603103
SCREW - MACH #6-32 x 3/8" SS
73
0290796
>TUBE - ROD HOLDER
112
2277001
>NUT - RETAINER RELEASE
35
050265
CONTROL BOARD - MAG 20 DT
74
2151726
>WASHER - 5/16" FLAT
113
2287002
>SPRING - RELEASE PIN
36
1296831
WIRE - CIRCUIT BREAKER JUMPER (RED)
75
2383106
>NUT - 5/16"-18 SS
114
2372100
>SCREW - #8 x 5/8" PPHMS [2.EA]
37
3398205
CIRCUIT BREAKER - 30 AMP
76
3319005
>CLAMP - ROD HOLDER w/ SLOT
115
3392600
>RELEASE PIN
38
1221490
UP/DN SWITCH BOOT
77
3325002
>DISK - ROD HOLDER
116
9010004
>BEARING - SWIVEL BASE [2.EA]
39
1221491
CIRCUIT BREAKER BOOT
78
9040310
>BOLT - HEX 5/16"-18 x 2"
117
2200107
OFFSHORE STACKER
* PARTS USED BUT NOT SHOWN
In the U.S.A., replacement parts may be ordered directly from CANNON Parts Dept., 121 Power Drive, Mankato, Minnesota 56001. In
Canada, parts may be ordered from any of the Canadian Authorized Service Centers shown on the enclosed list. Be
sure to provide the MODEL and SERIAL numbers of your downrigger when ordering parts. Please use the correct part numbers from
the parts list. Payment for any parts ordered from the CANNON parts department, may be by cash, personal check,
Discover Card, MasterCard or VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.
> PART OF ASSEMBLY
►
ITEM CANNOT BE SOLD SEPARATELY
Form No. 3394908 Rev 12/06
