Cannon Mag 20 Dt/Hs - Manual (Page 22)

1
3392500
FRAME - LARGE BLACK (LEXAN)
42
0467695
BRAKE PLATE - REEL
83
9430160
>WASHER - STAR 5/16" [3.EA]
2
4427005
NOSE DECAL MAGNUM
43
1264670
CLUTCH PAD
84
2277002
>UNIVERSAL LINE RELEASE
3
9040040
HOOK - 1/4" - 20 ROLLED
44
1433074
GEAR - DRIVER WORM
85
3998600
>UNI-STACKER RELEASE
4
2263102
NUT - HEX 1/4"-20
45
9010003
BEARING - DRIVE SHAFT NYLINER
86
3992300
SWIVEL HEAD ASSEMBLY
5
9280750
SCREW - 1/4" - 20 (RH) x 3/4" PPH
46
9400005
SPRING - SHAFT CONTACT
87
0267001
►
SIDE PLATE (RH)
6
0849615
BASE LOCK KNOB
47
4421002
COVER - GEAR CASE
88
0267002
►
SIDE PLATE (LH)
7
9040340
BOLT - 3/8"-16 X 1-1/2" HEX
48
2372100
SCREW - #8 x 5/8" PPHMS [5.EA]
89
0269726
►
PULLY - SWIVEL HEAD
8
9010001
BEARING - REEL SHAFT NYLINER [2.EA]
49
9010310
WASHER - THRUST [2.EA]
90
3397300
►
WASHER - .735 OD X .36 ID
9
9430210
WASHER - 1-1/16" OD X 7/8" ID (NYLON)
50
9010280
BEARING - THRUST
91
9010070
►
HDW BEARING BRASS[2.EA]
10
0220477
DEPTH COUNTER - 3 DIGIT
51
2998906
KNOB BRAKE
92
2227820
BOOM END - TELESCOPIC (LEXAN)
11
0833561
GEAR - COUNTER
52
0649001
►
KNOB - HAND ADJUST
93
2200148
SNAP & INSULATOR [2.EA]
12
0274000
REEL ASSEMBLY - HS ELECTRIC
53
9130390
►
NUT - KNURLED INSERT 3/8"-24
94
1007334
MOUNTING BASE (LEXAN)
13
0233560
>GEAR REEL
54
1479070
O-RING - REEL SHAFT
95
2994893
*BAG ASSEMBLY, MOUNTING (KIT #3)
14
0274731
►
REEL - MACHINED 3.75"
55
9370205
SCREW - 1/4" x 3/4" HEX WASH HD [3.EA]
96
2263102
NUT - HEX 1/4"-20 [4.EA]
15
1459666
REEL MAGNET [2.EA]
56
3993200
POWER CABLE ASSEMBLY
97
2371712
WASHER - 9/32" FLAT [4.EA]
16
1480071
SHAFT - REEL
57
3393200
>POWER CABLE - BATTERY
98
9100100
TERMINATOR
17
9340131
SCREW - SET 5/16"-18 x 1-3/4" (REEL)
58
3393201
>CAP - POWER CABLE - BATTERY
99
9100101
TERMINATOR CUSHION
18
3775397
SPOOL CABLE SS [400.FT]
59
3393202
>POWER CABLE - MOTOR
100
9100620
TERMINATOR SNAP & SWIVEL
19
9100070
CABLE LEADER SLEEVE [2.EA]
60
3393210
>CAP - POWER CABLE -MOTOR
101
9280725
BOLT - TRUSS 1/4" - 20 x 2-1/2" [8.EA]
20
3396530
MOTOR HOUSING - MAG 20 (LEXAN)
61
1458001
MOTOR 12V DC
102
9370010
SCREW - #4 x 1/2" PPH [3.EA]
21
1497071
LENSE - WINDOW DISPLAY
62
1497070
GEAR - WORM MOTOR
103
9950357
WASHER - LOCK 1/4" SPLIT [4.EA]
22
3395620
DECAL - LARGE, MAG 20 DT/HS
63
9250001
PIN - MOTOR, 3/32" X 3/4" ROLL SS
104
2210821
TELESCOPIC BOOM
23
3395702
DECAL - POSITIVE ION CONTROL
64
700032
TERMINAL - MOTOR, FEM 12-10 [2.EA]
105
2219822
>BASE TUBE CLAMP
24
2286792
SWITCH - UP/DN CONTROL
65
9010002
BEARING - MOTOR SHAFT
106
2219823
>MID TUBE CLAMP
25
2286793
WASHER - SHIM .750 x .1 UP/DN SWITCH
66
2263112
NUT - HEX #10-32 BZ
107
2222825
>MID TUBE COLLET
26
3395703
DECAL - PIC KNOB DIAL
67
1421072
COVER - MOTOR HOUSING (LEXAN)
108
2222826
>BASE TUBE COLLET
27
050268
CABLE ASSY - MAG20DT (DATA IN/OUT)
68
3393400
SCREW - #8-18 x 1-1/4" PPHSMS SS [6.EA]
109
2290828
►
BOOM BASE TUBE (BLACK)
28
050215
POSITIVE ION CONTROL POT
69
701007
O-RING - SMALL
110
2290829
►
BOOM MID TUBE (BLACK)
29
611005
KNOB - POSITIVE ION CONTROL
70
2332103
SCREW-#6-20 X 3/8"
111
2290830
►
BOOM END TUBE (BLACK)
30
700176
CAP - CONNECTION PORT [2.EA]
71
3395630
DECAL - CANNON LARGE [2.EA]
112
2998905
SWIVEL BASE
31
609209
CABLE ASSY - MAG20DT UP/DN SWITCH
72
3991902
BAG ASSY - DUAL REAR ROD HOLDER
113
2249001
>KNOB - RELEASE PIN (LEXAN)
32
609253
CABLE ASSY - ANTENNA IN (SENSOR)
73
0290796
>TUBE - ROD HOLDER [2.EA]
114
2267001
>BASE PLATE (LEXAN)
33
1234002
INSERT - 1/4" PRESS THD #6-32
74
2151726
>WASHER - 5/16" FLAT
115
2267002
>SWIVEL PLATE (LEXAN)
34
603103
SCREW - MACH #6-32 x 3/8" SS
75
2383106
>NUT - 5/16"-18 SS [3.EA]
116
2267006
>INDEXING PLATE (TAPPED)
35
050265
CONTROL BOARD - MAG 20 DT
76
2411386
>POST - REAR MOUNT (LEXAN)
117
2277001
>NUT - RETAINER RELEASE
36
1296831
WIRE - CIRCUIT BREAKER JUMPER (RED)
77
2411390
>BRACKET - DUAL ROD (LEXAN)
118
2287002
>SPRING - RELEASE PIN
37
3398205
CIRCUIT BREAKER - 30 AMP
78
2419470
>CLAMP - ROD HOLDER [2.EA]
119
2372100
>SCREW - #8 x 5/8" PPHMS [2.EA]
38
1221490
UP/DN SWITCH BOOT
79
3319005
>CLAMP - ROD HOLDER w/ SLOT
120
3392600
>RELEASE PIN
39
1221491
CIRCUIT BREAKER BOOT
80
3325002
>DISK - ROD HOLDER
121
9010004
>BEARING - SWIVEL BASE [2.EA]
40
1480070
SHAFT - DRIVE
81
9040310
>BOLT - HEX 5/16"-18 x 2" [3.EA]
41
9250002
PIN - DRIVE SHAFT 3/16" ROLL SS
82
9340101
>SCREW - SET 3/8"-16 x 5/8" [2.EA]
* PARTS USED BUT NOT SHOWN
In the U.S.A., replacement parts may be ordered directly from CANNON Parts Dept., 121 Power Drive, Mankato, Minnesota 56001. In
Canada, parts may be ordered from any of the Canadian Authorized Service Centers shown on the enclosed list. Be
sure to provide the MODEL and SERIAL numbers of your downrigger when ordering parts. Please use the correct part numbers from
the parts list. Payment for any parts ordered from the CANNON parts department, may be by cash, personal check,
Discover Card, MasterCard or VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.
> PART OF ASSEMBLY
►
ITEM CANNOT BE SOLD SEPARATELY
Form No. 3394903 Rev 12/06
