Cannon Mag 20 Dt/Hs - Manual (Page 24)

1
3392500
FRAME - LARGE BLACK (LEXAN)
42
9250002
PIN - DRIVE SHAFT 3/16" ROLL SS
83
9340101
>SCREW - SET 3/8"-16 x 5/8" [2.EA]
2
4427005
NOSE DECAL MAGNUM
43
0467695
BRAKE PLATE - REEL
84
9430160
>WASHER - STAR 5/16" [3.EA]
3
9040040
HOOK - 1/4" - 20 ROLLED
44
1264670
CLUTCH PAD
85
2277002
>UNIVERSAL LINE RELEASE
4
2263102
NUT - HEX 1/4"-20
45
1433074
GEAR - DRIVER WORM
86
3998600
>UNI-STACKER RELEASE
5
9280750
SCREW - 1/4" - 20 (RH) x 3/4" PPH
46
9010003
BEARING - DRIVE SHAFT NYLINER
87
3992300
SWIVEL HEAD ASSEMBLY
6
0849615
BASE LOCK KNOB
47
9400005
SPRING - SHAFT CONTACT
88
0267001
►
SIDE PLATE (RH)
7
9040340
BOLT - 3/8"-16 X 1-1/2" HEX
48
4421002
COVER - GEAR CASE
89
0267002
►
SIDE PLATE (LH)
8
9010001
BEARING - REEL SHAFT NYLINER [2.EA]
49
2372100
SCREW - #8 x 5/8" PPHMS [5.EA]
90
0269726
►
PULLY - SWIVEL HEAD
9
9430210
WASHER - 1-1/16" OD X 7/8" ID (NYLON)
50
9010310
WASHER - THRUST [2.EA]
91
3397300
►
WASHER - .735 OD X .36 ID
10
3320011
DEPTH COUNTER - 3 DIGIT (METRIC)
51
9010280
BEARING - THRUST
92
9010070
►
HDW BEARING BRASS[2.EA]
11
3333010
COUNTER GEAR (METRIC)
52
2998906
KNOB BRAKE
93
2227820
BOOM END - TELESCOPIC (LEXAN)
12
0854654
COUNTER CUSHION/STOPPER [2.EA]
53
0649001
►
KNOB - HAND ADJUST
94
2200148
SNAP & INSULATOR [2.EA]
13
3374010
REEL ASSY - HS ELECTRIC (METRIC)
54
9130390
►
NUT - KNURLED INSERT 3/8"-24
95
1007334
MOUNTING BASE (LEXAN)
14
0274731
►
REEL - MACHINED 3.75"
55
1479070
O-RING - REEL SHAFT
96
2994893
*BAG ASSEMBLY, MOUNTING (KIT #3)
15
3333011
>GEAR REEL (METRIC)
56
9370205
SCREW - 1/4" x 3/4" HEX WASH HD [3.EA]
97
2263102
NUT - HEX 1/4"-20 [4.EA]
16
1459666
REEL MAGNET [2.EA]
57
3993200
POWER CABLE ASSEMBLY
98
2371712
WASHER - 9/32" FLAT [4.EA]
17
1480071
SHAFT - REEL
58
3393200
>POWER CABLE - BATTERY
99
9100100
TERMINATOR
18
9340131
SCREW - SET 5/16"-18 x 1-3/4" (REEL)
59
3393201
>CAP - POWER CABLE - BATTERY
100
9100101
TERMINATOR CUSHION
19
3775397
SPOOL CABLE SS [400.FT]
60
3393202
>POWER CABLE - MOTOR
101
9100620
TERMINATOR SNAP & SWIVEL
20
9100070
CABLE LEADER SLEEVE [2.EA]
61
3393210
>CAP - POWER CABLE -MOTOR
102
9280725
BOLT - TRUSS 1/4" - 20 x 2-1/2" [8.EA]
21
3396530
MOTOR HOUSING - MAG 20 (LEXAN)
62
1458001
MOTOR 12V DC
103
9370010
SCREW - #4 x 1/2" PPH [3.EA]
22
1497071
LENSE - WINDOW DISPLAY
63
1497070
GEAR - WORM MOTOR
104
9950357
WASHER - LOCK 1/4" SPLIT [4.EA]
23
3395620
DECAL - LARGE, MAG 20 DT/HS
64
9250001
PIN - MOTOR, 3/32" X 3/4" ROLL SS
105
2210821
TELESCOPIC BOOM
24
3395702
DECAL - POSITIVE ION CONTROL
65
700032
TERMINAL - MOTOR, FEM 12-10 [2.EA]
106
2219822
>BASE TUBE CLAMP
25
2286792
SWITCH - UP/DN CONTROL
66
9010002
BEARING - MOTOR SHAFT
107
2219823
>MID TUBE CLAMP
26
2286793
WASHER - SHIM .750 x .1 UP/DN SWITCH
67
2263112
NUT - HEX #10-32 BZ
108
2222825
>MID TUBE COLLET
27
3395703
DECAL - PIC KNOB DIAL
68
1421072
COVER - MOTOR HOUSING (LEXAN)
109
2222826
>BASE TUBE COLLET
28
050268
CABLE ASSY - MAG20DT (DATA IN/OUT)
69
3393400
SCREW - #8-18 x 1-1/4" PPHSMS SS [6.EA]
110
2290828
►
BOOM BASE TUBE (BLACK)
29
050215
POSITIVE ION CONTROL POT
70
701007
O-RING - SMALL
111
2290829
►
BOOM MID TUBE (BLACK)
30
611005
KNOB - POSITIVE ION CONTROL
71
2332103
SCREW-#6-20 X 3/8"
112
2290830
►
BOOM END TUBE (BLACK)
31
700176
CAP - CONNECTION PORT [2.EA]
72
3395630
DECAL - CANNON LARGE [2.EA]
113
2998905
SWIVEL BASE
32
609209
CABLE ASSY - MAG20DT UP/DN SWITCH
73
3991902
BAG ASSY - DUAL REAR ROD HOLDER
114
2249001
>KNOB - RELEASE PIN (LEXAN)
33
609253
CABLE ASSY - ANTENNA IN (SENSOR)
74
0290796
>TUBE - ROD HOLDER [2.EA]
115
2267001
>BASE PLATE (LEXAN)
34
1234002
INSERT - 1/4" PRESS THD #6-32
75
2151726
>WASHER - 5/16" FLAT
116
2267002
>SWIVEL PLATE (LEXAN)
35
603103
SCREW - MACH #6-32 x 3/8" SS
76
2383106
>NUT - 5/16"-18 SS [3.EA]
117
2267006
>INDEXING PLATE (TAPPED)
36
050265
CONTROL BOARD - MAG 20 DT
77
2411386
>POST - REAR MOUNT (LEXAN)
118
2277001
>NUT - RETAINER RELEASE
37
1296831
WIRE - CIRCUIT BREAKER JUMPER (RED)
78
2411390
>BRACKET - DUAL ROD (LEXAN)
119
2287002
>SPRING - RELEASE PIN
38
3398205
CIRCUIT BREAKER - 30 AMP
79
2419470
>CLAMP - ROD HOLDER [2.EA]
120
2372100
>SCREW - #8 x 5/8" PPHMS [2.EA]
39
1221490
UP/DN SWITCH BOOT
80
3319005
>CLAMP - ROD HOLDER w/ SLOT
121
3392600
>RELEASE PIN
40
1221491
CIRCUIT BREAKER BOOT
81
3325002
>DISK - ROD HOLDER
122
9010004
>BEARING - SWIVEL BASE [2.EA]
41
1480070
SHAFT - DRIVE
82
9040310
>BOLT - HEX 5/16"-18 x 2" [3.EA]
* PARTS USED BUT NOT SHOWN
In the U.S.A., replacement parts may be ordered directly from CANNON Parts Dept., 121 Power Drive, Mankato, Minnesota 56001. In
Canada, parts may be ordered from any of the Canadian Authorized Service Centers shown on the enclosed list. Be
sure to provide the MODEL and SERIAL numbers of your downrigger when ordering parts. Please use the correct part numbers from
the parts list. Payment for any parts ordered from the CANNON parts department, may be by cash, personal check,
Discover Card, MasterCard or VISA. To order, call 1-800-227-6433 or FAX 1-800-527-4464.
> PART OF ASSEMBLY
►
ITEM CANNOT BE SOLD SEPARATELY
Form No. 3394922 Rev 12/06
