nstallation
Normal Tap without thread
&
screw type inlet hose
T. Unscrew the fixing screw to
attach the tap.
Upper
CcnredG
2.
Push the connector up till the
rubber packing is in tight contact
with the tap, Then tighten the 4
screws.
FklbberpBddnf]
Füdng screw
3.
Push the water supply hose
vertically upwards so that the
rubber packing within in the
hose can adhere completely to
the tap and then tighten it by
screwing it to the right.
Upper
C«irc(;lur
Normal Tap without thread & one touch type inlet hose (Single inlet models)
1.
Untighten the upper connector
2.
Push the upper connector up'
screw.
thA nihhpr n^rkinn iA in tinht
Fiiirg &318W
Rubb«i
packing
UtMl«
COniiKtoi
' In case the diameter of the tap is
large remove the guide plate
Guide plate
the rubber packing is in tight
contact with the tap. Then
tighten the 4 screws.
Rubber packng
Connecter-..
3.
Connect the water supply hose
to the middle connector,
pushing the plate down.
upper
Comector
Pi3ie
Connector
Middk—
connector
• Turn the middle connector not
to have water leaked.
Make sure that the rubber seal
is inside the hose connector.
HoM ponnector
Water Sjppljf
hose
To separate the water supply
hose from the middle connector
shut off the tap. Then pull the
inlet hose down, pushing the
plate down.
Us«d the horlizontal tap
Horizontal tap
Extension tap
Square tap
8
Rubber
îm
I
■ Your machine comes with only
cold water connection.
Make sure that there are no
kinks in the hose and that it is
not crushed.
