Installation
Cabinet Installation
1)
Open the window. Mark a line on center of the
window stool.
Carefully place the cabinet on the window stool and
align the center mark on the bottom front with the
center line marked in the window stool.
^ Pull the bottom window sash down behind the Upper
Guide until It meets.
: Do not pull the window sash down tightly that
the movement of Frame Curtain ® is restricted.
Window Sash
Foam-pe®
Upper guide
Cabinet
Frame Curtain©
Foam-pe®
3)
Loosely assemble the SHI Support ® using the parts
INDOOR
uuun I
h
^
V
Jj
Sill Support®
Bolt®-
OUTDOOR
Support®
'Nut®
^ Select the position that will place the Sill Support ®
near the outer most point on sill
tHiiiMd
: Be careful when you Install the cabinet
(Frame Guides ® are broken easily).
S)
Attach the Sill Support ® to the cabinet track hole in
relation to the selected position using 2 Type A
screws In each support
