Vi-3 – Century 15 User Manual
Page 5
VI-3
REF.
NO.
PART
NO.
REQ'D
NUMBER
DESCRIPTION
Section VI - PARTS (cont'd)
ALUMINUM BED ASSEMBLY
1
8
0300132
WIRE TIE
2
14
0300134
HOSE CLAMP
3
1
0300250
4 TON WINCH ASSEMBLY (STD)
0303273
4 TON PLANETARY WINCH ASSEMBLY (OPT)
4
1
0301669
CABLE ASSEMBLY
5
2
0301740
GROMMET, MARKER LIGHT
6
2
0301741
SEALED LAMP (RED)
7
2
0301742
SEALED LAMP (AMBER)
8
2
0302180
BEARING PAD (SPECIFY BODY LENGTH)
9
2
0306009
BEARING PAD, 60"
10
4
0400044
DRIVE SCREW
11
15
0400077
SCREW, 1/4" X 1" SELF DRILLING
12
8
0400088
SCREW, 1/4"-20 X 5/8" STAINLESS
13
6
0400177
SCREW, 1/2"-13 X 1-1/4" HEX HD CAP
14
4
0400181
SCREW, 1/2"-13 X 1-1/2" HEX HD CAP
15
2
0400213
SCREW, 3/8"-16 X 1-1/2" HEX HD CAP
16
3
0400392
NUT. 3/8"-16 HEX NYLOK
17
10
0400408
NUT, 1/2"-13 HEX NYLOK
18
4
0400492
WASHER, 1/2" FLAT
19
2
0701172
SPACER, WINCH BRACKET
20
4
0702517
BEARING PAD STOP BAR
21
1
0703203
COVER PLATE
22
1
0708913
ANTI-TILT PLATE
23
1
0710822L
MARKER LIGHT CASTING, LEFT
1
0710822R
MARKER LIGHT CASTING, RIGHT
24
1
0801482
WINCH MOUNTING BRACKET (STD WINCH)
0805215
WINCH MOUNTING BRACKET (OPT WINCH)
25
1
0806257
CARRIER BED (19' ALUMINUM)
1
0806437
R/R CARRIER BED (19' ALUMINUM)
26
1
0720283
HOSE TRAY (19' CARRIER)
0709851
HOSE TRAY (20' CARRIER)
0710777
HOSE TRAY (21' CARRIER)
27
1
0805178
CAB PROTECTOR WELDMENT (42" HIGH)
0805179
CAB PROTECTOR WELDMENT (45" HIGH)
0805180
CAB PROTECTOR WELDMENT (48" HIGH)
0805181
CAB PROTECTOR WELDMENT (52" HIGH)
0805182
CAB PROTECTOR WELDMENT (54" HIGH)
28
2
LT0118
FRONT MARKER LIGHT (AMBER)
