Vi-9 – Century 15 User Manual
Page 11
REF.
NO.
PART
NO.
REQ'D
NUMBER
DESCRIPTION
Section VI - PARTS (cont'd)
FRAME ASSEMBLY
(Continued from page VI-9)
36
20
0400392
NUT, 3/8"-16 HEX NYLOK
37
32
0400408
NUT, 1/2"-13 HEX NYLOK
38
16
0400421
NUT, 5/8"-11 NYLOK
39
2
0400452
LOCKWASHER, 1/4"
40
1
0400564
ROLL PIN
41
1
0500425
DECAL, CONTROL STATION (LEFT SIDE)
42
1
0500426
DECAL, CONTROL STATION (RIGHT SIDE)
43
2
0700584
CABLE
44
1
0702434
PIN, EXTEND CYLINDER
45
2
0704152
SPACER, MOUNTING BRACKET
46
1
0720080
MUD FLAP MOUNTING BRACKET, RH
47
1
0720081
MUD FLAP MOUNTING BRACKET, LH
48
2
0705092
BAR, MUDFLAP
49
1
0705239
SAFETY PIN
50
1
0705253
PLATE, LIGHT MOUNTING (LEFT SIDE)
51
1
0705254
PLATE, LIGHT MOUNTING (RIGHT SIDE)
52
1
0721546
PIVOT PIN (HINGE)
53
2
0801180
MOUNTING BRACKET
54
1
0306048
TOOL BOX
55
1
0801557
CONTROL BOX HOOD, LEFT
56
1
0801558
CONTROL BOX HOOD, RIGHT
57
1
0801559
CENTER CONTROL HOUSING
58
2
0802663
L-ARM STORAGE BRACKET
59
2
0802667
TOOL BOX MOUNTING BRACKET
60
1
0805745
MOUNTING FRAME
61
4
0806094
SHAFT, LIFT CYLINDER
62
1
0806274
TILT FRAME
--
--
--
BEDLOCK KIT
63
6
0400211
SCREW, 1/2"-13 X 1-3/4" HEX HD CAP
64
6
0400408
NUT, 1/2"-13 HEX NYLOK
65
12
0400492
WASHER, 1/2" FLAT
66
2
0720365
BEDLOCK GUIDE ANGLE
67
1
0805054
BEDLOCK ASSEMBLY
VI-9
