Vi-11 – Century 15 User Manual
Page 13
REF.
NO.
PART
NO.
REQ'D
NUMBER
DESCRIPTION
Section VI - PARTS (cont'd)
WHEEL LIFT & SLIDE-IN
TIRE RESTRAINT ASSEMBLY
1
7
0300113
GREASE FITTING
2
2
0301398
RATCHET, TIE DOWN (INCL SCREW & NUT)
3
8
0301642
SNAP RING, 1-1/4"
4
2
0301850
BEARING PAD
5
2
0301956
STRAP, RUBBER
6
2
0302368
CYLINDER, WHEEL LIFT LIFT
7
1
0308129
DETENT BALL
8
1
0308130
PIPE PLUG
9
1
0308131
DETENT SPRING
10
2
0308132
"O" RING
11
1
0400126
SCREW, 3/8"-16 X 1" HEX HD
12
1
0400148
SCREW, 3/8"-16 X 1-1/4" HEX HD CAP
13
2
0400161
BOLT, 3/8"-16 X 2-3/4" CARRIAGE
14
2
0400221
SCREW, 3/8"-16 X 1" CUP POINT ALLEN HD
15
2
0400367
NUT, 1/4"-20 HEX NYLOK
16
2
0400392
NUT, 3/8"-16 HEX NYLOK
17
2
0400393
NUT, 3/8"-16 HEX JAM
18
2
0400398
HALF NUT, 3/8"-16 HEX NYLOK
19
2
0400451
WASHER, 1/4" FLAT
20
3
0400480
WASHER, 3/8" FLAT
21
1
0403004
SCREW, 3/8"-16 X 3/4" BUTTON ALLEN HD
22
2
0500241
DECAL, SAFETY CHAIN WARNING
23
1
0702131
SHAFT, INNER TUBE CYLINDER
24
4
0702434
SHAFT, LIFT CYLINDER
25
1
0703277
SLIDER, PAD
26
1
0705524
SHAFT, EXTEND CYLINDER
27
1
0720460
PIN, CROSSBEAM PIVOT
28
1
0720463
WASHER, 1" O.D. X 3/8" I.D. FLAT
29
2
0800583
PIVOT, TIE DOWN
30
2
0800590
"T" HANDLE
31
1
0801009
SHAFT, PIN ASSEMBLY, UPPER BOOM
32
2
0801332
TIRE RESTRAINT
33
1
0805245
INNER BOOM
34
1
880360500
CROSSTUBE WELDMENT
35
1
0805470
OUTER CROSSTUBE, RIGHT
36
1
0805471
OUTER CROSSTUBE, LEFT
37
1
0806109
OUTER BOOM
VI-11
