CRAFTSMAN ROUTER - MODEL NO. 315.275000
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your ROUTER or when ordering repair parts.
SEE BACK PAGE FOR PARTS ORDERING INSTRUCTIONS
PARTS LIST
Key No. Part No. Description Quan.
1
973689-001 Labe!....................................................................................... . 1
2 999053-003
*
Screw (#5-10
X
1/2 in. Fil. Hd.)................................................. . 1
3 973671-001 Actuator Button............................................................................. . 1
4 989592-002 Screw (#8-10 X 1-3/8 in. Fil. Hd.).............................................. .3
5 975778-001 Data Plate............................................................................................... . 1
6
974289-001 Caution Label.......................................................................................... . 1
7 975779-001 Logo Plate......................................................................... .................... . 1
8 973688-002 Pointer.............................................................................................. . 1
9 612556-003
*
Screw (#8-18
X
9/16 in. Fil. Hd. T.C.).................................................. . 4
10 974098-001 Lower Bearing Plate............................................................................... . 1
11 974516-001 Screw (#4-40 x 3/4 in. Pan Hd.) ......................................................... .2
12
974239-003 Ring Assembly....................................................................................... . 1
13 610120-005
*
Screw (#6-10
X
3/4 in. Pan Hd.) ......................................................... .8
14 97^811-001 Auxiliary Handle Assembly..................................................................... . 1
15 616968-003
*
Screw (#6-20 X 5/8 in. Pan Hd. T.C.) .................................................. .2
16 726676-002
*
Set Screw (#8-32 x 7/1
6
in. Flat Point)............................................... . 1
17 623924-007 Needle Roller.......................................................................................... . 1
18 973669-001 Depth Lock Lever................................................................................... .. 1
19 622347-020 Spring Washer........................................................................................ .. 1
20 970712-002
*
Shoulder Screw (#10-32 X 5/16 in. Pan Hd.)........................................ . 1
21 974323-002 Shaft Lock Label..................................................................................... .. 1
22 974908-011 Base Assembly (Includes Key No. 17)................................................... .. 1
23 973672-001 Chip Shield.............................................................................................. .. 1
24 975810-001 Power Handle Assembly......................................................................... .. 1
25 998895-001 Switch Trigger........................................................................................ .. 1
26 973986-100 Lamp Base.............................................................................................. .. 1
27 616445-001
*
Screw (#8-18X5/8 in. Fil. Hd.)............................................................... ..2
28 644328-001 Bulb........................................................................................................ .. 1
29 973968-001 Lens........................................................................................................ .. 1
30 614661-001
-*
Screw (#10-32 X 1/2 in. Flat Hd.)......................................................... .. 1
31 998586-001
*
Screw (#10-32 X 1/4 in. Pan Hd.) ........................................................ ..4
32 973668-002 Subbase.................................................................................................. .. 1
33 607896-001 Retaining Ring........................................................................................ ..2
34 974252-003 1/2 in. Collet Assembly (Inc. Key No. 33 And One Of Key No. 36).. .. 1
35 974252-005 1/4 in. Coliet Assembly (Inc. Key No. 33 And One Of Key No. 36).. .. 1
36 974096-001 Shoulder Screw....................................................................................... .. 2
37 973844-001 1/2 in. Collet Nut.................................................................................... .. 1
38 974518-001 Wrench.................................................................................................. .. 1
39 976242-001 Optional Edge Guide.............................................................................. .. 1
40 976269-001
***
Optional Guide Bushing Adapter............................................................ ..
1
41 060721-630
***
Optional Guide Bushing w/Nut (1/4 in. x 5/16 in.)............................... ..
1
42 060721-530 Optional Guide Bushing w/Nut (1/4 in. x 3/8 in.)................................ .. 1
43 060721-430
* * *
Optional Guide Bushing w/Nut (1/2 in. x 5/8 in.)................................ .. 1
44 060721-030 Optional Guide Bushing w/Nut (11/32 in. x 7/16 in.).......................... .. 1
972000-416 Owner’s Manual
NOTE: "A The assembly shown represents an important part of the Double Insulated System. To avoid
the possibility of alteration or damage to the system, service should be performed by your nearest Sears
Repair Center. Contact your nearest Sears Retail Store for Service Center information.
* Standard Hardware Item — May Be Purchased Locally
***
..... ....
Optional Accessory (Not Shown) — Available At Your Nearest Sears Retail Store
