PARTS LIS
I
Self-Propelled Mower — Model No. 247.37683
J
Ref. No.
Part No.
Description
1
747-1214
Drive Controi
2
710-0599
TT Screw 1/4-20x0.5
3
736-0270
Beii Washer.265 x 0.75
4
17032A
Defiector Chute Adapter
5
732-1014
Torsion Spring
6
918-04376A
Transmission Assembiy
7
747-1161A-0637
Blade Control
8
749-1092A-0637
Upper Handle
9
731-04177
Chute Deflector
10
987-02055
Mulch Plug Complete
11
747-0710
Hinge Pin
12
782-7551A
Wheel Dust Cap
13
720-0279
Handle Knob
14
720-04072A
Star Knob
15
710-1205
Eye Bolt
16
746-1113
Control Cable
17
710-1174
Carriage Bolt 5/16-18x2.0
18
656-04045A
Pulley Assembly, Drive
19
926-0240
Cable Tie
20
731-2626
Bail Cover
21
710-0654A
Self-Tapping Sems Screw
22
746-04203
Drive Cable
23
964-04115
Grass Bag
24
710-1650
Shoulder Screw # 12 -24
25
987-02347
Front Bearing Assembly
26
710-1241
Screw, 1/4-15x1.000
27
987-02194A
Height Adjustment Ass'y - RH
987-02193A
Height Adjustment Ass'y - LH
28
787-01278-0691
21” Deck
29
731-04150C
Rear Baffle
30
912-0397
Wing Nut
31
750-04595
Slev. Spacer 1.4” Lg.
32
710-0216
Hex Screw, 3/8-16 x.75
33
732-04090A
Torsion Spring - RH
34
712-04065
Flange Lock Nut, 3/8-16
35
931-05132A
Transmission Cover
36
782-5002B
Front Baffle
Ref. No.
Part No.
Description
37
954-0637A
V-Belt
38
936-0447
Wave Washer
39
750-04594
Sleeve Spacer 8.985” Lg.
40
748-04082
Blade Adapter, 25mm
41
942-0741
21” Mulching Blade
42
736-0524B
Blade Bell Support
43
987-02334
Pivot Plate Assembly
44
710-1257
Hex Screw 3/8-24 x 2.50
45
749-0928A-0637
Lower Handle
46
732-1043
Belt Tension Spring
47
720-0426
Adjustment Knob
48
731-06847
Rear Discharge Door
49
634-0190
Front Wheel
50
710-04531
Screw, 1/4-20
X
.390
51
717-1762
Gear 14T RH FWD
717-1761
Gear 14T LH FWD
52
747-04080A-0637
Grass Bag Frame
53
710-0703
Carriage Bolt 1/4-20
54
916-0102
Snap Ring
55
710-1652
TT Scr. w/Washer 1/4-20 x.625
56
987-02271A
Handle Bracket Assembly - RH
987-02270A
Handle Bracket Assembly - LH
57
915-0221
Dowel Pin
58
736-0474
Washer
59
987-02333
Pivot Arm Assembly - RH
987-02332
Pivot Arm Assembly - LH
60
732-04175
Rear Spring Lever
61
738-04266
Shoulder Scr.500 Dia. x.434
62
734-1987
Rear Wheel
63
736-04389
Wave Washer
64
732-0706
Front Lever - RH
732-0707
Front Lever - LH
65
747-04587
Pivot Rod
66
731-05642A
Rear Trailing Shield
67
931-06029
Engine Baffle
68
787-01593
Engine Baffle Bracket
