OPERATION
Figure 6
A Speed Control Lever / Parking Brake Lever
B Throttle/choke control lever
C Ignition Switch Module
D Deck Lift Lever
E PTC Lever (Blade Engage)
F Cup Holder
G Shift Lever
H Seat Adjustment Lever
I Clutch-Brake Pedal
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator's seat position facing forward towards
the front of tractor._ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Meets ANSI Safety Standards
Craftsman Tractors conform to the safety standard of the American National Standards Institute (ANSI).
12
