then tighten the multi-function handle to blower
with the two screws (Fig. 3, H).
FIGURE 3
4. Once the handle is secured, the blower tube with
;■ handle can be twisted and swiveled. Ensure that
the throttle cable does not become pinched or
trapped when swiveling handle.
5. Install the extension tube (if desired) onto blower
tube by aligning the tab on the extension with the
corresponding area on blower tube; then push
together and twist to secure.
6. Install the curved nozzle tube in the same manner.
Twist to secure.
OPERATION
KNOW YOUR BACKPACK AIR BLOWER
Read this Operator’s Manual and Safety Instmctions before operating your backpack air blower. Compare the
illustration below (Figure 4) with your backpack air blower to familiarize yourself with the location of various controls
and adjustments. Save this manual for future reference.
1. On-off switch 12. Anti-vibration springs
2. Throttle lever 13. Quick release carrying strap
3. Speed lever 14. Carrying strap
4. Primer 15. Carrying frame
5. Choke lever 16. Pleated tube
6. Air filter cover 17. Blower tube
7. Fuel tank cap 18. Extension tube
8. Starter rope handle 19. Curved nozzle tube
9. Sparkplug 20. Blower housing
10. Muffler 21. Clamp
11. Carburetor adjustment screws 22. Clamp with cable guide
FIGURE 4
