CRAFTSMAN COMPOUND MITER SAW - MODEL NUMBER 315.212130
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
PARTS LIST FOR FIGURE D
KEY
PART
KEY
PART
NO.
NUMBER
DESCRIPTION
QUAN.
NO.
NUMBER
DESCRIPTION
QUAN.
1
976641-001
"O" Ring............................ ............................ 1
. 15
982900-001
Data Plate................................. .................... 1
2
976576-001
Lock Pin............................. ............................ 1
16
976650-001
Spindle Lock Pin..................... .................... 1
3
976643-001
E-Ring................................ ............................ 1
17
976651-001
E-Ring....................................... .................... 1
4
976644-001
* Screw (M4 X 16 Pan Hd.)............................... 1
18
976649-001
Compression Spring............... .................... 1
5
976645-001
Rubber Bumper................ ............................ 1
19
976654-001
* Square Key (4 x 4 x 28)........... ....................1
6
“STD851012
* Flat Washer {Ml 2)............ ............................ 1
20
588030-008
Gear Shaft................................ .................... 1
7
" STD841217
* Hex Nut (Ml2).................... ............................ 2
21
976658-001
* Ball Bearing (6004zz).............. .................... 1
8
180031-002
* Depth Stop Adjustment Screw (M10 x 20)..1
22
588031-004
Screw (Special)........................ ....................
2
9
**STD841015
‘Hex Nut (M10)..................... ............................ 1
23
976653-001
Lock Ring................................. .................... 1
10
976682-001
Brush Cap......................... ............................ 2
' 24
588028-108
Gear.......................................... .................... 1
11
976683-001
Brush Assembly............... ............................ 2
25
976648-001
External Retaining Ring.......... .................... 1
12
976691-001
Warning Label................... ............................ 1
26
976647-001
* Ball Bearing (6000zz).............. .................... 1
13
982102-001
* Screw (M6
X
25 Pan Hd.)... ............................ 2
27
A63020000428
“0” Ring.................................... .................... 1
14
511311000
Top Handle........................ ............................ 1
972000-905
Owner’s Manual
* Standard Hardware Item — May Be Purchased Locally
** Available From
Div.
98 — Source 980.00
w
Ol
NOTE: "A"-The assembly shown represents an important part of the Double Insulated System. To avoid the possibility of alteration or damage
to the system, service should be performed by your nearest Sears Repair Center. Contact your nearest Sears Catalog Order or
Retail Store for Service Center Information.
