FEATURES
CARRYING HANDLE
See Figure 4.
For convenience when carrying or transporting your
miter saw from one place to another, a carrying
handle has been provided on top of the saw arm as
shown in figure 4. To transport, turn off and unplug
your saw, then lower the saw arm and lock it in the
down position. Lock saw arm by depressing the lock
pin.
CARRYING
HANDLE
MITER LOCK HANDLE
See Figure 4.
The miter lock handle securely locks your saw at
desired miter angles.
Fig. 4
SPINDLE LOCK BUTTON
See Figure 5.
A spindle lock button has been provided for locking
the spindle which keeps the blade in your saw from
rotating. Depress and hold the lock button while
installing, changing, or removing blade only.
SWITCH
TRIGGER
SPINDLE
LOCK BUTTON
Fig. 5
TRIGGER LOCK
See Figure 6.
To prevent unauthorized use of your compound miter
saw, we suggest that you disconnect it from the power
supply and lock the switch in the off position. To lock
the switch, install a padlock (not included) through the
hole in the switch trigger. A lock with a long shackle
up to 17/64 in. diameter may be used. When the lock
is installed and locked, the switch is inoperable. Store
the padlock key in another location.
SWITCH
TRIGGER
PADLOCK
Fig. 6
11
