Craftsman 315.212130 - Manual (Page 29)

CRAFTSMAN COMPOUND MITER SAW - MODEL NUMBER 315.212130
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts. _______________ _____________
PO
CO
PARTS LIST FOR FIGURE A
KEY
NO.
PART
NUMBER DESCRIPTION QUAN.
KEY
NO.
PART
NUMBER
1 710308-045 * Bolt (M8 X 45 Soc. Hd.)............... ................ 2 17 976515-001
2 ** STD852008 ’ Lock Washer (M8)........................ ................ 4 18 976509-001
3 511101000 Fence ........................................... ................ 1 19 976527-001
4 511102000 Miter Fence.................................. ................ 1 20 ** STD851004
5 980117-001 * Bolt (M8 X 25 Soc. Hd.)............... ................ 2 21 976506-001
6 976516-001 Zero Clearance Throat Plate...... ................ 1 22 976505-001
7 160030-400 * Screw (M4 X 8 Flat Hd.)............... ................ 4 23 976501-001
8 976569-001 8 mm Hex Key.............................. ................ 1
24 ** STD852006
9 976605-001 6 mm Hex Key.............................. ................ 1 25 700306-025
10 982611-001 5 mm Hex Key.............................. ................ 1 26 976578-001
11 976568-001 Blade Wrench........................... . ................ 1 27 ** STD851010
12 976598-001 Cover Plate................................... ................ 1 28 976511-001
13 976601-001 * Screw (M4 X 9 Pan Hd.).............. ................ 2 29 976513-001
14 976531-001 Rivet.............................................. ................ 3
30 976610-001
15 977434-001 Hand Warning Label.................... ................. 2
31 976514-001
16 977435-001 Line Label..................................... ................. 2
32 511103000
DESCRIPTION QUAN.
Miter Scale..................................................... 1
Miter Lock Plate.............................................1
Screw (M4 X 10 Pan Hd.)...............................1
Flat Washer (M4)........................................... 1
Pointer............................................................1
Miter Lock Handle......................................... 1
Control Arm................................................... 1
Lock Washer (M6)......................................... 2
Screw (M6 X 25 Soc. Hd. Cap)..................... 2
Nylon Lock Nut (M10)................................... 1
Washer (M10).................................................2
Spring Washer (M10).................................... 1
Table Spindle.................................................1
Miter Table Frame
{Includes Key Nos. 14, 15, 16, & 17)........... 1
Miter Table..................................................... 1
Fence Screw.................................................. 1
Dr Standard Hardware Item — May Be Purchased Locally
Available From Div. 98 — Source 980.00
