PARTS LIS
I
Self Propelled Mower — Model No. 247.887760
J
Ref. No.
Part No.
Description
1
647-0004
Blade Control
2
753-0717
Upper Control Housing
3
731-0620A
Drive Control
4
753-0717
Lower Control Housing
5
710-1667A
C Sunk Tap Screw, #10 x.75 Lg
6
753-0717
Cable Mounting Cap
7
746-071 IB
Drive Cable
8
728-0199
Rivet
9
925-04347
Key Switch
10
925-0201
Key
11
746-04639
Control Cable
12
749-04354A-0637
Upper Handle
13
720-04072A
Star Knob
14
710-1652
Screw, 1/4-20 x .625
15
710-1174
Carriage Bolt, 5/16-18 x 2.0
16
926-0240
Cable Tie
17
749-0907B
Lower Handle
18
931-0066
Adapter Assembly
19
731-1832
Side Discharge Chute
20
931-1833A
Mulch Cover
21
782-0078B-4028
Deck 21”
22
912-0397
Wing Nut
23
710-0703
Carriage Bolt, 1/4-20 x .75”
24
914-0104
Cotter Pin
25
726-0233
Push Nut, .25
X
ID
X
.50 OD
26
950-1071
Sleeve Spacer, .88ID x 1.130D
27
756-0612A
Half Pulley: 2.62 OD
28
756-0613
Half Pulley: 2.62 ODx 1.61
29
741-0545
Ball Bearing
30
682-7527
Cup
31
748-0377E
Blade Adapter
32
736-0524B
Blade Bell Support
33
710-1257
Hex Bolt, 3/8-24 x 2.5
34
742-0741A
21” Mulching Blade
35
710-0653
Screw, 1/4-20x3.75
36
731-1828
Baffle
37
954-0460
Belt, 3/8
X
39.24
Ref. No.
Part No.
Description
38
710-0895
Screw, 1/4-15
X
.750
39
964-04093A
Grass Catcher
40
747-0940A-0637
Support Rod w/ Rope Guide
41
747-0939
Pivot Rod
42
747-0937-0637
Grass Catcher Frame
43
631-0071
Grass Catcher Cover
44
926-0106
Cap Nut
45
712-04063
Flange Lock Nut, 5/16-18
46
731-1874A
Chute Door
47
732-0819
Torsion Spring
48
726-0111
Push Cap
49
747-0965
Pivot Rod
50
925-04323
12V Battery
51
710-0654A
Sems Screw, 3/8-16 x 1.00
52
925-04072
Harness Assembly
53
936-0526
Wave Washer, 1.38 ID x.88 OD
54
950-1070
SIve Spacer, .88 ID x 1.00 OD
55
782-7596A
Control Arm
56
932-0807
Torsion Spring
57
711-1114
Pivot Shaft
58
782-7597
Pivot Bracket
59
738-0924A
ShIder Screw, .375 ID x 1/4-14
60
756-0625
Cable Roller
61
710-0134
Carriage Screw, 1/4-20 x .62
62
936-0329
Lock Washer, 1/4
63
782-7575B-0637
Cable Mounting Bracket
64
746-0939A
6 Speed Cable
65
782-7574A-0637
Cable Adjustment Bracket
66
712-04064
Hex Nut 1/4-20
67
912-0138
Hex Nut 1/4-28
68
732-0627A
Shift Lever Spring
69
731-0924
6 Speed Shift Lever
70
913-0397
Gear Insert
71
16864
6 Spd. Rack Cable Bracket
72
956-061 ЗА
Pulley Assembly
73
725-04329
12V Battery Charger
