UNASSEMBLED PARTS

(1) Wheel

Mower Front Wheel

(1) Shoulder Bolt

(1) Locknut 3/8-16

(1) 1-1/4 O.D. Washer

Mower

(5) Large Retainer

Springs - 7/16

(1) 3/4 O.D. Washers

(1) Front Link

Assembly

(2) Small Retainer

Springs - 5/16

(5) 1 -3/16 O.D. Washers

(1) Anti-Swar Bar

(2) Rear Lift Link

Assemblies

(1) Oil Drain Tube
For Future Use

Slope Sheet

(2) Keys

ASSEMBLY/PRE-OPERATION

Your new tractor has been assembled at the factory with exception of those parts left

unassembled for shipping purposes. To ensure safe and proper operation of your tractor

all parts and hardware you assemble must be tightened securely. Use the correct tools
as necessary to ensure proper tightness.
