FEATURES
KNOW YOUR DRILL-DRIVER
See Figure 1.
Before attempting to use this product, familiarize yourself
with ali operating features and safety rules.
err STORAGE
Bits provided with the drill-driver can be placed in the
storage area, located on the base of the drill.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
Your drill-driver has a direcdon of rotation (forward/reverse/
center lock) selector located above the switch trigger for
changing the direction of bit rotation. Setting the switch
trigger in the OFF (center locl^ position helps reduce the
possibility of accidental starting when not in use.
KEYLESS CHUCK
The keyless chuck allows you to hand-tig hten or release
the drill bit in the chuck jaws.
LEDWORKLIGHT
The LED worklight, located on the front of the tool base,
illuminates when the switch trigger is depressed. This
provides extra light for increased visibility.
LEVEL
A level is located on the top of the motor housing to help
you keep the drill bit level during use.
TORQUE ADJUSTMENT RING
Your drill-driver has a 24-position clutch. The torque
adjustment ring can be turned Co select Che right amount
of torque tor your application.
VARIABLE SPEED
The variable speed switch trigger delivers higher speed
with increased trigger pressure and lower speed with de­
creased trigger pressure.
ASSEMBLY
UNPACKING
This product has been shipped completely assembled.
■ Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list
are included.
■ Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
m Do not discard the packing material until you have
caretulty inspected and satisfactorily operated the tool.
■ If any parts are damaged or missing, please cad
1 -000-932-3188 for assistance.
PACKING UST
Drill-Driver
Battery Pack (2)
Chffl’ger
Double-ended Bits
Carrying Case
Operator’s Manual
WARNING: If any parts are missing do not operate
this tool until the missing parts are replaced. Failure
to do so could result in possible serious personal
injury.
WARNING: Do not attempt to modify this tool
or create accessories not recommended for use
with this tool. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possible serious personal injury.
WARNING: To prevent accidental starting that
could cause serious personal injury, always remove
the battery pack from the tool when assembling
parts.
