CRAFTSMAN COMPOUND MITER SAW - MODEL NUMBER 315.212100
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
COMPOUND MITER SAW or when ordering repair parts.
PARTS LIST FOR FIGURE C
g
KEY PART KEY PART
NO. NUMBER DESCRIPTION QUAN. NO. NUMBER
1 976539-001 Dust Shield................................... ................... 1 14 130030-401
2 976596-001 U-Clip........................................... ................... 2
15 976547-001
3 976567-001 Dust Guide................................... ................... 1
16
**•
4 976543-001 Upper Blade Guard...................... ................... 1
17 976548-001
5 979678-001 Logo Plate.................................... ................... 1
18 976554-001
6 976599-001 Screw (M5x 12)............................ ................... 4
19 976607-001
7 976733-001 Lower Blade Guard Label........... . ................... 1
20 976608-001
8 976540-001 Caution Label................. .............. ................... 1
9 976604-001 Phillips Screw............................... ................... 1
21 976507-001
10 976600-001 Fixed Screw.................................. ................... 1
22 130030-501
.11 976552-001 Blade Bolt Cover.......................... ................... 1
23 976740-001
12 976549-001 Lock Nut.................. .................... ................... 1
24 976564-001
13 976541-001 Stopper............. .......................... .................. 1
DESCRIPTION QUAN.
Screw (M4 X 15).............................................. 1
Blade Washer......................................... .....2
Saw Blade .................................................... 1
Blade Bolt (M8 X 20)..................................... 1
Return Spring................................................ t
Lower Blade Guard Assembly......................... 1
Blade Guard Bracket Assembly
(Includes Key No. 23)..........................................................1
Washer (M5)................................................... 1
Screw (M5 X 10).............................................. 1
Label...............................................................1
Screw.............................................................. 1
